Steel Suction Cups with Bonded Seal, 5000 - 6000 series
For horizontal handling of heavy loads (thick sheet metal) or objects with an uneven surface such as concrete slabs or wood, etc.
Advantage: wide choice of shapes and dimensions.
Industry-specific applications
Types of use
Keypoints
- For horizontal handling of heavy loads (thick sheet metal) or objects with an uneven surface such as concrete slabs or wood, etc
5020
STEEL SUCTION CUPS DIA 150 MM WITH BM2020SPTR- Form: Flat
- Type of suction cup: Round
- Diameter (ØA) | mm: 150
- Suction cup material: Nitrile (NBR)
- Fitting: G1/4"-F
5028
STEEL SUCTION CUPS DIA 170 MM WITH BM2020SPTR- Form: Flat
- Type of suction cup: Round
- Diameter (ØA) | mm: 170
- Suction cup material: Nitrile (NBR)
- Fitting: G1/4"-F
5035
STEEL SUCTION CUPS DIA 190 MM WITH BM2020SPTR- Form: Flat
- Type of suction cup: Round
- Diameter (ØA) | mm: 190
- Suction cup material: Nitrile (NBR)
- Fitting: G1/4"-F
5050
STEEL SUCTION CUPS DIA 210 MM WITH BM2020SPTR- Form: Flat
- Type of suction cup: Round
- Diameter (ØA) | mm: 210
- Suction cup material: Nitrile (NBR)
- Fitting: G1/4"-F
5085
STEEL SUCTION CUPS DIA 260 MM WITH BM2020SPTR- Form: Flat
- Type of suction cup: Round
- Diameter (ØA) | mm: 260
- Suction cup material: Nitrile (NBR)
- Fitting: G1/4"-F
5150
STEEL SUCTION CUPS DIA 350 MM WITH BM3030SPTR- Form: Flat
- Type of suction cup: Round
- Diameter (ØA) | mm: 350
- Suction cup material: Nitrile (NBR)
- Fitting: G3/8"-F
5240
STEEL SUCTION CUPS DIA 420 MM WITH BM3030SPTR- Form: Flat
- Type of suction cup: Round
- Diameter (ØA) | mm: 420
- Suction cup material: Nitrile (NBR)
- Fitting: G3/8"-F
5330
STEEL SUCTION CUPS DIA 500 MM WITH BM3030SPTR- Form: Flat
- Type of suction cup: Round
- Diameter (ØA) | mm: 500
- Suction cup material: Nitrile (NBR)
- Fitting: G3/8"-F
5500
STEEL SUCTION CUPS DIA 580 MM WITH BM3030SPTR- Form: Flat
- Type of suction cup: Round
- Diameter (ØA) | mm: 580
- Suction cup material: Nitrile (NBR)
- Fitting: G3/8"-F
